OPERATION

Moving the writing surface

Use the auxiliary cable to connect the COM Port on the PC and the PC COM connector (9 pins) on

the board to the auxiliary serial cable.

Install the board ware software in the PC.

Use the board ware software to download the writing surface data to the PC.

The PC ONLINE lamp on the unit switch panel lights up when the boardware starts up and

the "Repeat" key changes to the "Download" key. The Repeat function is now inoperable.

Consult the board ware software manual for the connect installation and operation of the

software.

Moving with the keys.

Press the Feed/Stop key. When the key is

pressed, the writing surface moves to the left

the equivalent of one page and then stops.

If the Feed/Stop key is pressed during

movement, the unit immediately stops.

Moving manually

It is also possible to move the writing surface

manually. The sheet can be moved in this

case either to the left or right. Avoid moving

the writing surface too quickly manually as

this could cause malfunctioning.

Downloading data to the PC

Making Additional Copies (Repeat)

To make a single copy

Press the Repeat key.

The 1 additional sheet is printed out from data

that was just copied.

There is no need to set several sheets

when making only 1 copy.

To make additional copies

Set the number of copies needed with the

[+] or [-] keys.

Press the Repeat key.

The copies are printed out from data that was

just copied.

A maximum of 99 copies can be set.

The Stop key is disabled during printout.

Be sure to set the correct number of copies.

PLUS BOARDFAX

BF-030SPP

POWER

POWER ON

PC ON LINE

REPERT



STOP

FEED

ERROR

DONWLOAD

Download key

PC ONLINE LAMP

1 2 ... 5 6 7 8 9 10 11 12 13 14 15
